SikaProof®-808

PRE-APPLIED FULLY BONDED FPO SHEET MEMBRANE FOR BASEMENT
WATERPROOFING

SikaProof®-808 is a FPO based sheet membrane for below ground waterproofing of reinforced concrete structures. It is loosely laid onto a prepared substrate below the base slab before fixing reinforcement and casting concrete. A special hybrid bonding layer on the membrane forms a permanent bond with the fresh concrete and prevents lateral water migration between the membrane and the concrete structure. Overlap joints are sealed using cold-applied tapes or by thermal jointing. The total thickness is 1,00 mm.

  • Pre-applied: Fixed before placing reinforcement and casting concrete

  • A+ Technology: Integral functional layer for chemical and mechanical bond with concrete structure
  • High flexibility and crack-bridging capabilities
  • No lateral water migration between concrete structure and membrane system
  • Easy to install with fully adhered joints
  • Overlap joints are sealed using thermal jointing or cold-applied tapes
SikaProof®-808
Product Data Sheet Show all documents

Usage

The Product is used for:
  • Damp-proofing, waterproofing and concrete protection for basements against ground water ingress.
Suitable for use on:
  • Reinforced concrete base slabs
  • Extension and reconstruction work

Advantages

  • Pre-applied: Fixed before placing reinforcement and casting concrete

  • A+ Technology: Integral functional layer for chemical and mechanical bond with concrete structure
  • High flexibility and crack-bridging capabilities
  • No lateral water migration between concrete structure and membrane system
  • Easy to install with fully adhered joints
  • Overlap joints are sealed using thermal jointing or cold-applied tapes

Packaging

Roll width

Roll length

1.00 m or 2.00 m

25 m

Refer to the current price list for available packaging variations.

Colour

Colour

Light grey

Surface texture

Rough surface on A+ bonding layer

Product Details

Sustainability / Certifications / Approvals

ENVIRONMENTAL INFORMATION

  • Certified Green Label product under Singapore Green Building Council (SGBC), 4 tick Leader.

APPROVALS / STANDARDS

  • CE marking and declaration of performance based on EN 13967:2012 Flexible sheets for waterproofing — Plastic and rubber damp proof sheets including plastic and rubber basement tanking sheet — Definitions and characteristics

  • General testing ASTM, Admaterials Technologies, Test report No. T20-16252

  • Watertightness functional test PG FBB Part 1, WISSBAU, Test report No. 2021-083-1

  • Watertightness functional test PG FBB Part 1, WISSBAU, Test report No. 2020-378-1
Product Information

Chemical Base

Membrane Layer

FPO

Bonding Layer

Cement modified polymer

(A+ Technology)

Shelf Life

18 months from date of production



Storage Conditions

The Product must be stored in original unopened and undamaged sealed packaging in dry conditions and temperatures between +5 °C and +30 °C. Store in a horizontal position. Do not stack pallets on top of each other.

Effective Thickness

Total thickness (1.00 +0.10 / -0.05) mm

(EN 1849-2)

Thickness TPO layer 0.80 mm

Mass per Unit Area

(1.00 +0.10 / -0.05) kg/m2

(EN 1849-2)
System information

System Structure

The following system products must be used in the pre-applied system:

  • SikaProof®-808 sheet membrane

  • SikaProof® Tape-120 for detailing and for internal jointing
Technical Information

Resistance to Impact

Method B

≥ 800 mm

Resistance to Static Puncture

≥ 500 N

(ASTM E0154)

Tensile Strength

Longitudinal (MD) Method A

≥400 N / 50mm

Transversal (CMD) Method A

≥400 N / 50mm

Longitudinal (MD) Method A

≥10 MPa

Transversal (CMD) Method A

≥10 MPa

Elongation at break

Longitudinal (MD) Method A

≥500 %

Transversal (CMD) Method A

≥500 %

Longitudinal (MD) Method A

≥700 %

Transversal (CMD) Method A

≥700 %

Crack Bridging Ability

No cracks occurred after 100 cycles at 3.2 mm width

(ASTM C1305)

Adhesion in Peel

≥ 60 N / 50 mm with 90° angle after 28 days

(ASTM D903)

Resistance to tear (nail shank)

≥ 300 N

(EN 12310-1)

Joint Shear Resistance

≥100 N / 50mm

(EN 12317-2)

Service Temperature

Maximum

+35 °C

Minimum

-10 °C

Foldability at Low Temperature

No cracks at -29 °C

(ASTM D1970)

Water Tightness

Method B (24 hours, 60 kPa)

Pass

Resistance to lateral water migration

Up to 7 bar (71 m)

Pass

Exposure to Bitumen

28 days, +70 °C

Pass

Method A (24 hours, 60 kPa)

Pass

Durability of Water Tightness against Chemicals

28 days, +23 °C

Pass

24 hours, 60 kPa

Pass

Durability of Water Thightness against Ageing

12 Weeks, +70 °C

Pass

Method B (24 hours, 60 kPa)

Pass

Reaction to Fire

Class E

(EN 13501-1)

Application

Application Information

Ambient Air Temperature

Maximum

+45 °C

Minimum

+5 °C

Substrate Temperature

Maximum

+60 °C

Minimum

+5 °C
Application steps

APPLICATION INSTRUCTIONS

IMPORTANT

Strictly follow installation procedures

Strictly follow installation procedures as defined in Method Statements, application manuals and working instructions which must always be adjusted to the actual site conditions.

SUBSTRATE QUALITY

SikaProof®-808 membrane must be applied on a sufficiently stable substrate to avoid movement during the construction works.

The substrate surface must be smooth, uniform and clean. Use Geotextile ≥300 g/m2 to protect the Product from sharp aggregates on the blinding concrete surface.

The substrate can be damp or slightly wet, avoid ponding water.

APPLICATION

IMPORTANT

Application by trained personnel

The application of this Product must only be carried out by an applicator that is trained or approved by Sika. The applicator must also be experienced in this type of application.


IMPORTANT

Unsuitable weather conditions for application

Do not install the membrane during continuous or prolonged rain, snowfall or sandstorm. 


IMPORTANT

Penetrations and construction joints

Additional Sika joint sealing solutions must be used for connections around penetrations and for construction joints.




IMPORTANT

Covering the membrane system

Permanent exposure to UV light will reduce the performance of the membrane system.

  1. Concrete must be placed within 60 days after membrane system installation.
  2. Proper concrete installation (mix design and workmanship) is required to achieve optimum bond of the membrane system to the concrete.

Reference must be made to the Sika Method Statement: SikaProof®-808
